From Surface Growth to Electron Diffraction: An Interactive MBE and RHEED Tutorial

MBE growth and RHEED oscillations

Kinetic Monte Carlo (KMC) simulation of molecular-beam-epitaxy growth. Deposition, thermally activated surface diffusion, downward step barriers and desorption on a periodic solid-on-solid lattice, with a step-density RHEED proxy plotted alongside the surface morphology.

The plotted RHEED signal is a step-density proxy, not a diffraction calculation; a separate kinematic diffraction module computes the screen itself. Scope and known limitations: STATUS.md. Source paper: nanomaterials-12-03052.pdf (CC BY). MIT licensed, except the paper and the three Wikimedia schematics: LICENSE.

Results so far

Work in progress; the open items are listed in STATUS.md. The figures below and the stored notebook demos are all generated on a 128x128 lattice, the largest size the finite-size study covers.

Oscillations against the paper's Figure 3, for three Ga/N ratios. Left is digitized from the published figure, right is a five-seed 128x128 ensemble of this model. The model oscillates at 0.94 to 0.96 ML in all three conditions, against 1.05 ML for the digitized Ga/N = 0.82 trace; the other two reference periods are less well defined. The proxy amplitude stays six to eight times smaller than the figure-derived signal, which is why the two panels keep separate scales (make figure3).

The surface behind those oscillations, 0 to 2 ML of homoepitaxial growth. Each layer fills before the next nucleates, which is what makes the proxy oscillate (make figure3).

The same surfaces seen across all three Ga/N conditions at the two points that define the oscillation: a half-filled layer and a closed one. Rows are coverage, columns are Ga/N, and every panel comes from the ensemble the comparison above already ran, so the figure costs no extra simulation (make figure3).

At 0.50 ML the surface is islanded and peaks; at 1.00 ML the layer has closed and drops by roughly half, which is the whole of why the proxy oscillates. Across the columns the trend is monotonic in both rows: raising Ga/N from 0.68 to 0.89 lowers from 0.113 to 0.079 at half coverage and from 0.056 to 0.030 at layer completion, so the richer Ga conditions sit closer to ideal layer-by-layer filling. This is homoepitaxial GaN throughout - no strain, no Stranski-Krastanov transition and no quantum dots are modelled or claimed.

Final RMS roughness against temperature and flux, 128x128, six seeds per point. This is an exploratory sweep beyond the paper, not a RHEED-oscillation regime map: 0/54 runs pass the oscillation test, so roughness rather than amplitude carries the map. Roughness falls with flux (1.90 to 1.55 ML at 700 K) and rises with temperature (1.90 to 2.34 ML at 0.25 ML/s), with a seed spread under 0.02 ML. The detrended proxy amplitude stored alongside it rises weakly over the same corners, 0.088 to 0.099, but that is a range about the linear trend of a decaying curve, not an oscillation amplitude (make sweep).

The notebook adds the interactive versions: a rotatable surface, playback over the recorded frames, and a frame slider tied to the RHEED trace. make export writes the whole thing to outputs/mbe_rheed.html.

How it works

Why kinetic Monte Carlo

RHEED oscillations are a kinetic effect, not an equilibrium one: the same temperature and flux give layers or mounds depending on whether atoms find a step edge before the next layer starts landing on them. So the method has to follow individual events in real time. Molecular dynamics would resolve lattice vibrations at femtoseconds, while a diffusion hop happens on microseconds and growing one monolayer takes seconds, which is far too many timesteps to reach. Rate equations integrate faster but average the surface away, and the surface is exactly what the RHEED signal responds to.

KMC sits between the two: it keeps individual events but skips the waiting between them, jumping straight from one event to the next with the correct exponential waiting time. The paper this project follows (Budagosky and Garcia-Cristobal, 2022) uses KMC for the same reason.

The surface

The lattice is solid-on-solid: one integer column height per site, so there are no overhangs and no buried vacancies. Sites sit on a hexagonal lattice with six neighbours, stored in axial coordinates on a periodic square array (lattice.py).

Three things can happen to that surface:

• Deposition: an atom lands on a uniformly random site, at total rate for flux (ML/s) and sites. It does not depend on the surface.
• Diffusion: a top atom hops to one of its six neighbours, allowed only when the two columns end up within one height of each other. That constraint is what keeps the surface single-valued.
• Desorption: a top atom leaves the surface.

Diffusion and desorption are thermally activated, so each site gets an Arrhenius rate with the barrier built up from the local environment (kmc.py):

Event	Barrier
Diffusion	, plus when the hop goes down a step edge
Desorption

is the number of same-height neighbours. An atom with many neighbours is harder to move or remove, which is what makes islands stable and edges grow. is the extra cost of hopping down an edge (the Ehrlich-Schwoebel barrier); raising it traps atoms on top of islands and produces mounds instead of flat layers.

One KMC step

Time is continuous, from the residence-time algorithm: sum all rates, draw the waiting time from that sum, then pick one event with probability proportional to its own rate.

sequenceDiagram
    autonumber
    participant U as Notebook or CLI
    participant K as KMC loop
    participant C as Rate catalogue
    participant L as Height field
    participant O as Observables

    U->>K: config: T, flux, barriers, size, seed, stopping criterion
    K->>L: start from an empty surface
    K->>C: build a rate for every possible event

    loop until target coverage or physical time
        C-->>K: total rate R
        K->>K: waiting time -ln(u) / R, advance the clock
        K->>C: draw one event with probability r / R
        C-->>K: deposition, or a hop, or a desorption
        K->>L: apply it: one or two columns change height
        K->>C: refresh rates around the changed columns only
        opt every sampling interval
            L-->>O: current height field
            O-->>K: coverage, roughness, island density, 1 - S_d
        end
    end

    K-->>U: heights, traces and snapshots

Two choices keep this fast enough to stay interactive, and both matter because the paper works at 256x256 while an honest comparison needs many seeds:

• Rates in a Fenwick tree. Picking an event by cumulative rate is a tree descent rather than a scan over every site, so selection costs log N instead of N.
• Local refresh. An event changes at most two columns, so only their neighbourhoods get recomputed instead of the whole lattice. The inner loop of that bookkeeping is compiled with Numba (fastpath.py), which is what MBE_KMC_BACKEND selects between.

There is also an optional approximation: an isolated atom on open terrace may cross several sites in one selected event (max_isolated_hop_distance). It is off by default, and make validate-acceleration measures what it costs against exact nearest-neighbour runs.

One trajectory is inherently sequential, since each event changes the surface the next event is drawn from. Only independent runs parallelise, which is why the batch workflows exist.

The RHEED proxy

is the fraction of neighbour bonds whose two sites have different heights, so it measures how much step edge the surface has (observables.py). The plotted signal is : high on a completed, flat layer, low when a layer is half filled and covered in island edges. One oscillation per monolayer follows from that, which is the same argument used for real specular RHEED intensity. It stays a morphology measure: no electron scattering enters it. The kinematic diffraction calculation below is a separate observable, computed from the same height fields but never fed back into the proxy.

The paper's Figure 3 puts its own simulated signal next to measured GaN oscillations (originally from Adelmann et al., 2002), which is the panel this project digitizes and compares against. What can be checked that way is period, phase and damping; absolute amplitude cannot, since the two signals are different quantities.

Where the interference is

counts step edges and stops there. The reason a step-edge count tracks a measured intensity at all is interference, which is what the diffraction module below actually computes, so it is worth writing out once.

The probe is a fast electron, so it arrives as a plane wave and, in the kinematic approximation, scatters once off each surface scatterer. The scattered amplitudes add with the phase of the position they came from, and the detector measures the squared modulus:

Squaring the sum is where the quantum mechanics enters. is not a count of scatterers: it carries one cross term per pair, so the screen reports relative positions. Nothing else in this project uses the phases; throws them away.

On the specular beam the in-plane part of vanishes, with , so every in-plane position drops out and only the column heights survive. That is why the specular trace is a layer-occupancy interferometer. For two terraces one monolayer apart, covering fractions and of the surface:

That last term is the oscillation. At the anti-phase condition (or any odd multiple) the cosine is , the two populations subtract, and normalizing on a flat surface leaves the closed form

which is 1 on a closed layer, 0 at half coverage, and 1 again when the next layer closes: one oscillation per monolayer, with no morphology argument anywhere in it. At the in-phase condition the cosine is , filling a layer changes nothing, and the oscillation disappears - which is why the grazing angle is an experimental knob and why antiphase_grazing_angle_deg exists. Because KMC heights are integers, only the parity of reaches the specular intensity: orders 1, 3, 5 give the same trace.

is the classical shadow of that cosine. It is large when one height dominates and small when two heights share the surface, so it follows the same flat -> mixed -> flat sequence for a geometric reason instead of an interference one - which is also why its amplitude is a different quantity from a measured intensity. Both come off the same height field: the morphology proxy carries no wave, while is kinematic interference.

The two-level formula above is only the illustrative case; rheed.py sums the real height distribution over the whole illuminated patch, which is what produces damping as the surface roughens past two levels.

The kinematic diffraction screen

Separately from the proxy, rheed.py computes what a detector would actually collect, in the kinematic (single-scattering) approximation: each occupied column contributes one scatterer at the top of its stack, and the screen follows the exact Ewald construction of Liu, Chang and Zou (2022) rather than a flat-Ewald approximation. It gives the full angular screen, the specular intensity against coverage, and which rods are reachable at a given beam energy, grazing angle and azimuth. Dynamical (multiple) scattering is still not computed, so absolute intensities remain model quantities.

The notebook paints the computed screen on the beam-geometry view, and the specular trace sits beside so the two observables can be compared. make validate-rheed checks the geometry against analytic and published values with tolerances; make rheed-visuals is the picture companion, on surfaces whose answer is known.

How the pieces connect

flowchart LR
    C["SimulationConfig"] --> K["kmc.run"]
    P["paper.py<br>Figure 3 parameters"] --> C
    K --> R["SimulationResult<br>heights, traces, snapshots"]
    R --> A["analysis.py<br>period, damping, amplitude"]
    R --> H["rheed.py<br>kinematic screen and specular intensity"]
    R --> W["workflows.py<br>runs seeds and parameter points in worker processes"]
    A --> S
    H --> S
    W --> S["scripts + Makefile"]
    S --> O["outputs/<br>figures, JSON, NPZ"]
    S --> D["data/processed<br>committed notebook inputs"]
    D --> N["notebook"]
    G["data/gallery<br>stored demo runs"] --> N
    K --> N
    H --> N

src/mbe_rheed_sim/ holds the physics and knows nothing about marimo or plotting; src/mbe_rheed_notebook/ holds the widgets and figures. The notebook can either run the model live or read the committed artifacts, which is why it opens instantly when presenting.

Setup

Requires Git and uv; make is optional. Python 3.12 is pinned in .python-version, dependencies in uv.lock; uv installs both, so nothing else has to be on the machine - no system Python, no compiler.

git clone <repo>
cd SCIQIS-MBE-RHEED-project
uv sync          # or: make setup, which refuses to change the lockfile

Getting uv (and make)

macOS - Homebrew, or the standalone installer:

brew install uv          # curl -LsSf https://astral.sh/uv/install.sh | sh

make comes with the Xcode command line tools (xcode-select --install).

Linux - the standalone installer works on any distro:

curl -LsSf https://astral.sh/uv/install.sh | sh

make is usually already there; otherwise sudo apt install make / sudo dnf install make.

Windows - PowerShell, or winget:

winget install --id=astral-sh.uv -e    # irm https://astral.sh/uv/install.ps1 | iex

There is no make on Windows by default and you do not need one. Every target in the Commands table below is a one-line uv run command, and the table shows it: make figure3 is uv run python scripts/run_workflow.py figure3, make notebook is uv run marimo edit notebooks/mbe_rheed.py --no-token --port 2718, make test is uv run pytest. Two syntax differences in PowerShell:

$env:MBE_KMC_BACKEND = "reference"; uv run pytest     # not MBE_KMC_BACKEND=... uv run
uv run python scripts/run_workflow.py figure3 --workers 4   # not make figure3 WORKERS=4

If you would rather use the make targets, install Git for Windows and run the commands from Git Bash with make from Chocolatey (choco install make), or work inside WSL and follow the Linux instructions.

Poppler (pdftocairo) is only needed for make digitize-figure3, never for setup or reproduction: brew install poppler, sudo apt install poppler-utils, or winget install oschwartz10612.Poppler.

Checking it worked

uv run pytest                                      # make test
uv run python scripts/run_workflow.py baseline     # make reproduce

The baseline is an 8x8, 1 ML run that verifies event counts and a final-height SHA-256, so it finishes in seconds and tells you the physics matches the committed reference on your machine.

If the setup will not cooperate: Docker

A fallback for a machine that fights the install - a locked-down laptop, a broken toolchain, a Python that cannot be replaced. Docker is the only thing needed, and the same two commands work on Windows, macOS and Linux (on Windows use Docker Desktop with the WSL 2 backend):

docker build -t mbe-rheed .
docker run --rm -p 2718:2718 mbe-rheed

Then open http://localhost:2718. The image is about 880 MB and builds in well under a minute once Docker has pulled its base image. It carries the committed gallery, so the pre-computed demos work the moment it starts, and live runs work too, at whatever speed the container gets. It is built from uv.lock, so the environment is the one uv sync would give you.

Anything else runs the same way, with the command in place of the default:

docker run --rm mbe-rheed uv run pytest
docker run --rm mbe-rheed uv run python scripts/run_workflow.py baseline

There is no make in the image, so use the uv run form from the Commands table. .git is copied in and git is installed, so artifacts built here carry the same commit and dirty-tree provenance as they would on the host. The container is disposable: --rm throws it away on exit, and anything it wrote goes with it. To keep figures and saved runs, mount the output directory over it - -v "$PWD/outputs:/project/outputs", or -v "${PWD}/outputs:/project/outputs" in PowerShell.

Notebook

make notebook    # uv run marimo edit notebooks/mbe_rheed.py --no-token --port 2718

Section 5 asks where results come from:

• Pre-computed demo (default) loads a stored trajectory from data/gallery/ instantly. Good for presenting. Seven runs: layer-by-layer growth with the paper's GaN parameters, island growth, step-barrier mounding, too-cold and too-high-flux roughening, pure random deposition, and a Stranski-Krastanov wetting layer. Six are 128x128, about 3 MB in total, so a laptop that cannot afford that lattice still gets it; the Stranski-Krastanov entry is recorded at 256x256 because the ordered phase its switch draws is only fully resolved there, and it loads with that switch already on. make gallery rebuilds them and fails if the measured roughness ordering or oscillation periods stop matching the captions.
• Simulate now runs the model live, with either hand-tuned parameters or the paper's fitted GaN values. Nothing runs until Run simulation is pressed. Runs estimated above 20 s, or on a 64x64-or-larger lattice, ask for a second confirmation. One trajectory cannot be split across cores, so a large lattice on a slow machine takes what it takes: if you are waiting too long, go back to the pre-computed demos, which cover the same physics at 128x128.

Section 3's surface views carry one optional overlay, the Stranski-Krastanov regime switch. The primary paper grows strained GaN on AlN, where the wetting layer stops growing layer-by-layer at a couple of monolayers and the surface reorders; this model has neither strain nor reconstruction, so it cannot produce that, and the switch appends a prescribed ordered phase past the run's target coverage to show what the transition would look like in the same observables. Everything measured from those surfaces - coverage, roughness, island density, the proxy, and the order parameter whose threshold crossing fixes the quoted transition coverage - is computed by the ordinary mbe_rheed_sim.observables functions, so the numbers are real measurements of a prescribed surface. It needs a live run of at least 64x64 to resolve, and it says so instead of doing nothing when the lattice is too small. Nothing in mbe_rheed_sim can reach it, so no saved run, gallery entry or workflow artifact is affected.

Section 4 carries the Figure 3 comparison and, below it, the two morphology figures shown above. Both are the committed PNGs rather than interactive plots: a 128x128 surface is 16k sites, and drawing six of them as live markers costs tens of thousands of SVG nodes and a page that stops responding. The interactive surface, hex-cell and step-edge views work on the smaller lattices section 2 runs, where they are responsive and worth having.

One trajectory cannot use more than one core, since each event mutates the surface the next event is sampled from. Cores only help across independent runs, which is what the batch workflows are for; run them with make or scripts/run_workflow.py, then reopen the notebook to pick up the promoted data.

If you have not used marimo before

marimo is a notebook that is a plain Python file. There is no JSON, no hidden state and no cell execution order to remember: it reads the variables each cell defines and uses, and reruns whatever depends on what you just changed. That is why editing a slider updates the figure below it without a "Run all". The consequences you notice while reading notebooks/mbe_rheed.py:

• Cells are @app.cell functions, listed in reading order but executed in dependency order.
• A variable can only be defined by one cell. Locals prefixed with _ are private to their cell, which is why the file is full of _values, _error and friends.
• uv run python notebooks/mbe_rheed.py runs it as a script, which is what make check uses.

What this notebook actually uses, all from import marimo as mo:

Piece	Why it is here
mo.md	every text cell; f-strings interpolate live values into the prose
mo.ui.slider, dropdown, radio, checkbox, number, text	the parameter controls; read the current value with .value
mo.ui.form	wraps a group of controls so nothing downstream reruns until Submit
mo.ui.run_button	Run simulation; keeps a long run from starting on every keystroke
mo.stop	early-exit a cell with a message instead of running the expensive part
mo.state	the one thing a widget cannot hold: the current playback frame
mo.ui.refresh	a timer cell; drives frame playback
mo.vstack, mo.hstack, mo.accordion, mo.callout	layout and the warning/error boxes
mo.status.progress_bar	progress during a live run

The pattern used throughout is: a cell assigns a mo.ui element to a global (it is not interactive otherwise), a later cell reads element.value, and marimo reruns that later cell on its own. mo.state only appears where that one-way flow is not enough - a value that has to survive being written by two different cells, such as the frame slider and the playback timer both setting the current frame.

Commands

Every workflow name is both a make target and a scripts/run_workflow.py argument, so make <name> is always uv run python scripts/run_workflow.py <name> - use whichever your shell has. The non-workflow targets are listed with their commands at the bottom of the table.

Command	What it does
make reproduce	8x8, 1 ML, seed 2026 baseline; checks event counts and the final-height SHA-256
make figure3	128x128, five seeds x three Ga/N ratios over 40 s vs. the published Figure 3
make figure3-parameters	prints the Figure 3 flux conversion, fitted barriers, rate diagnostics
make sweep	128x128 six-seed temperature/flux heatmap (notebook input)
make convergence, make figure3-convergence	finite-size sensitivity; add SIZES=8,16,32,64 for the ~2 min 64x64 point
make validate-acceleration, -science, -sweep	accelerated vs. exact ensembles and model trends
make benchmark-sizes	sequential 64/128/256 runtime envelope
make validate-rheed	32x32 flat/stepped/rough screens, analytic and published-geometry checks
make rheed-visuals	uv run python scripts/export_rheed_visuals.py --size 128; writes outputs/rheed_visuals.pdf
make preset-pdf	uv run python scripts/export_preset_pdf.py --size 128; one page per preset, outputs/preset_gallery.pdf
make gallery	rebuild the stored notebook demos, six at 128x128 plus the 256x256 Stranski-Krastanov entry; SIZES=<one size> changes the six
make readme-figures	rerun figure3 + sweep, then copy the four PNGs from outputs/figures/ into assets/
make test	uv run pytest
make check	uv run ruff check ., uv run marimo check --strict notebooks/mbe_rheed.py, uv run python notebooks/mbe_rheed.py
make export	uv run marimo export html notebooks/mbe_rheed.py -o outputs/mbe_rheed.html -f

Output goes to outputs/, which is Git-ignored and can always be rebuilt. Committed notebook inputs live in data/processed/, figure-derived reference curves in data/reference/, and the display-only Stranski-Krastanov template in data/reconstruction/.

make digitize-figure3 re-extracts the reference curves from page 10 of the paper. It is the only command that needs a non-Python tool (pdftocairo from Poppler), and it is not part of setup, CI or normal reproduction. What it extracts are panel coordinates read off the figure, not raw experimental values, and they stay separate from the model's own .

Execution details

Backend. The hot path runs through compiled Numba kernels. They repeat the reference NumPy path's floating-point operations in the same order, so trajectories are bit-identical either way and MBE_KMC_BACKEND only changes speed:

MBE_KMC_BACKEND=reference make test   # pure NumPy, no compiler
MBE_KMC_BACKEND=fast make figure3     # error out instead of falling back silently

Compilation happens once per machine (~1.2 s, cached in src/mbe_rheed_sim/__pycache__), so timing one short run measures cache loading, not throughput.

Workers. Independent seeds and parameter points run in bounded spawn processes. Precedence: --workers, then MBE_WORKERS, then min(10, os.cpu_count() - 1). Convergence sizes run one after another while the seeds within a size run concurrently, to keep memory down. Baseline reproduction and the timing benchmark stay sequential, since running them in parallel would defeat the point.

make figure3 WORKERS=4
make convergence WORKERS=1 SIZES=8,16 SEEDS=0,1   # debugging/CI fallback

Provenance. Each run writes to outputs/batches/<UTC timestamp>-<workflow>/ with a manifest, progress log, stdout/stderr, source revision, configuration and artifacts. Only a run that finished cleanly takes the promotion lock and atomically replaces the canonical files, so a failed or interrupted batch can never become a notebook input.

Logs. Stage and completed-count progress goes to stderr, so make <workflow> shows progress while the JSON summary on stdout stays pipeable. MBE_LOG_LEVEL=WARNING|DEBUG turns the volume down or up; 2>/dev/null | jq . keeps only the JSON.

Layout

notebooks/mbe_rheed.py       narrative and reactive wiring only
src/mbe_rheed_sim/           physics and reproducible execution (no marimo, no plotting)
  rheed.py                   kinematic diffraction screen, separate from the 1-S_d proxy
src/mbe_rheed_notebook/      notebook widgets and figures (marimo + Plotly)
scripts/                     baseline, Figure 3, validation, sweep entry points
tests/                       scientific and software invariants
data/                        gallery demos, committed inputs, reference curves
Dockerfile                   the setup fallback; see the Docker section above

A marimo notebook is one file and cannot be split, so everything except narrative and wiring is imported from src/mbe_rheed_notebook/. That also makes the widget and figure logic testable without launching a notebook (tests/test_notebook.py). Two marimo rules to remember when editing: a mo.ui element only becomes interactive if a cell assigns it to a global, and a cell may not reassign a variable another cell defines (hence the _-prefixed locals).

Troubleshooting

• uv: command not found: install uv (Setup) and open a new shell , the installer adds ~/.local/bin (or %USERPROFILE%\.local\bin) to PATH only for new sessions.
• make: command not found / 'make' is not recognized: you do not need make. Run the uv run command from the Commands table instead.
• Python 3.12 missing: uv python install.
• Lockfile mismatch: uv lock, check the dependency change, commit uv.lock.
• Marimo token or port trouble: close old tabs, then make notebook MARIMO_PORT=2721.
• Import errors: run commands from the repository root after uv sync.
• Baseline hash changed: don't just update it. Find out which model or dependency change moved it first.
• Setup still broken after all that: build the Docker image and work from the container instead.
